| Sensor | Thermocouple, platinum resistance thermometer, analog input (voltage, current) can be switched |
| Storage Temperature | -25 to 65℃ (no condensation or freezing) |
| Type of Product | Temperature Controller |
| Input Type | Thermocouple / resistance temperature detector / sensor / current / voltage |
Sensor |
Thermocouple, platinum resistance thermometer, analog input (voltage, current) can be switched |
Storage Temperature |
-25 to 65℃ (no condensation or freezing) |
Type of Product |
Temperature Controller |
Input Type |
Thermocouple / resistance temperature detector / sensor / current / voltage |
Model No |
E5CC-QQ3DSM-001 |
Control Output |
Voltage output (for driving SSR) / Voltage output (for driving SSR) |
Character Height (mm) |
PV：15.2, SV：7.1 |
Monotaro ID |
46675632 |
Power Supply Voltage |
AC 24(50/60 Hz) /DC 24 V |
Length (mm) |
60 |
Mass (g) |
Main unit: Approx. 120, Mounting adapter: Approx. 10 |
Applicable Standard |
EN 61010-1(IEC 61010-1), RCM |
Shape |
Din 48x48 |
Terminal Shape |
Screw terminal block |
Country of Origin |
INDONESIA |
Control |
ON/OFF or 2 degrees of freedom PID (with auto tuning) |
Import Country |
Direct Import from Japan |
Pattern Setting |
Digital setting with front keys |
Standard |
[Certification standards] cULus: UL 61010-1/CSA C22.2 No.61010-1, KOSHA (S mark) certification (some models only), Korea Radio Regulations (Radio Act: KC mark) (some models only), Lloyd's standard |
Protection Class |
Front: IP66, Rear case: IP20, Terminal part: IP00 |
Operating Temperature Range |
-10 to 55℃ (no condensation or freezing) / 3-year warranty: -10 to 50℃ (no condensation or freezing) when installed as standard |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Power Consumption (W) |
2.3 or less |
Specifications |
●Multi-SP function: Up to eight target values (SP0 to SP7) can be stored and selected by event input, key operation, or serial communication●[Effects of electromagnetic interference (according to EN 61326-1)] Thermocouple input (R, S, B, C/W, PLⅡ): (±1% of indicated value or ±10°C, whichever is greater) ±1 digit or less Other thermocouple input: (±1% of indicated value or ±4°C, whichever is greater) ±1 digit or less Platinum resistance thermometer input: (±1% of indicated value or ±2°C, whichever is greater) ±1 digit or less Analog input: ±1%FS ±1 digit or less, CT input: ±5%FS ±1 digit or less Remote SP input: ±1%FS ±1 digit or less Recommended fuse: T2A, AC 250 V time lag low breaking capacity Installation environment: Overvoltage category II, pollution degree 2 (EN/IEC/UL 61010-1) Manual reset value: 0.0 to 100.0% (in 0.1% increments) Configuration tool port: Top: Use the USB-serial conversion cable E58-CIFQ2 to connect to the USB port on the PC |
Other functions |
Output for external indicator light (non-safety output): Connectable indicator light/incandescent lamp: DC 24 V, 3-7 W, ・LED lamp: Load current 10 to 300 mA, leakage current 1 mA or less (To use the external indicator output, the general-purpose indicator cord Model F39-JJ3N or the dedicated external indicator kit Model F39-A01P□-PAC is required.) |
Remark |
Confirm Delivery Date Each Time |
