| Type of Product | Digital Indicating Controller |
| Accuracy | Thermocouple: Within ±0.2% of each input span ±1 digit, Resistance thermometer: Within ±0.1% of each input span ±1 digit, DC current/voltage: Within ±0.2% of each input span ±17 digits |
| Input Type | Thermocouple, RTD, DC current, DC voltage |
| Model No | DCL-33A-S/M1W(10A) |
Type of Product |
Digital Indicating Controller |
Accuracy |
Thermocouple: Within ±0.2% of each input span ±1 digit, Resistance thermometer: Within ±0.1% of each input span ±1 digit, DC current/voltage: Within ±0.2% of each input span ±17 digits |
Input Type |
Thermocouple, RTD, DC current, DC voltage |
Model No |
DCL-33A-S/M1W(10A) |
Control Output |
Relay contact/non-contact voltage/DC current |
Color |
Black |
Display |
PV (red, 4 digits), SV (green, 4 digits) |
Voltage |
Non-contact voltage (for driving SSR): 12DC ±15% |
Monotaro ID |
57571905 |
Length (mm) |
100 |
RoHS Directive |
Correspondence |
Sampling Period (ms) |
141 |
Country of Origin |
Japan |
Control |
Auto tuning PID・PI・PD・P・ON/OFF |
Import Country |
Direct Import from Japan |
Optional |
DC current input shunt resistor (50Ω) |
Included Components |
Simplified instruction manual: 1 copy, Heater break alarm output [option: W (5A, 10A, 20A)] added: Connector harness W3m 1 set, CT (CTL-6-SH) 1 piece |
Name of Manufacturer/Packer/Importer |
Shinko Technos |
Width (mm) |
22.5 |
Power Supply Voltage (V) |
AC/DC24 |
Options |
Heater break alarm output (10A) |
Height (mm) |
75 |
Altitude (m) |
2000 or less |
