| Type of Product | Thermocouple Input |
| Model No | AFP7FCRTC2 |
| Input Impedance | 344 kΩ |
| Monotaro ID | 28635086 |
Type of Product |
Thermocouple Input |
Model No |
AFP7FCRTC2 |
Input Impedance |
344 kΩ |
Monotaro ID |
28635086 |
Vibration Resistance |
5 to 8.4 Hz, single amplitude 3.5 mm, 1 sweep / minute (IEC61131-2), 8.4 to 150 Hz, constant acceleration 9.8m/s2 10 sweeps (1 octave / min) (IEC6111-2) |
Shock Resistance |
147m/s2 or more 3 times each in X, Y, Z directions (IEC61131-2) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Ambient Humidity to Use |
10 to 95% RH (at 25°C, no condensation), Storage: 10 to 95% RH (at 25°C, no condensation) |
Insulation Type |
Between thermocouple input terminal and internal digital circuit: transformer insulation, isolation IC insulation, between thermocouple input terminals: transformer insulation, isolation IC |
Number of Input Points |
2ch (isolated between channels) |
Input Range |
Thermocouple K: -50.0 to 500.0°C, Thermocouple J: -50.0 to 500.0°C |
Connection Type |
Connector type terminal block |
Noise Resistance |
1,000V[PP] pulse width 50ns, 1μs (by noise simulator method) |
Overall Accuracy |
±0.5% FS or less + cold junction error: 1.5°C (0 to 55°C) |
RoHS Directive |
Correspondence |
Sampling Cycle |
100ms/2ch |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Current Consumption (mA) |
45 or less |
Operation Ambient Temperature (°C) |
0 to +55, when saving: -40 to +70 |
Mass of Main Unit (g) |
Approx. 25 (including terminal block) |
Resolution (℃) |
0.2 (displayed as 0.1 with software averaging) |
