| Model No | FRL-3-02A |
| Type of Product | Filter + Regulator + Lubricator Unit |
| Material | Aluminum alloy |
| Monotaro ID | 9592624 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
FRL-3-02A |
Type of Product |
Filter + Regulator + Lubricator Unit |
Material |
Aluminum alloy |
Monotaro ID |
9592624 |
Operating Temperature Range |
5 - 60°C |
Suitable Fluid |
Air |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
MonotaRO |
Import Country |
Direct Import from Japan |
Pipe Connection Diameter |
PT1/4 |
Pressure Gauge Connection Size |
46030 |
Maximum Operating Pressure (MPa) |
1 |
Drain Port Size (Rc) |
46030 |
Lubricator Oil Capacity (mL) |
150 |
Maximum Flow Rate (LPM) |
1750 |
Recommended Oil |
ISO VG-32 |
Minimum Working Pressure (MPa) |
0.2 (entrance side) |
Set Pressure Unit |
MPa |
LID Material |
Polyacetal |
Thread Type |
PT |
Filtration |
5 μ |
Assured Pressure Resistance (MPa) |
1.2 |
Material (Ball Guard) |
Zinc alloy |
Bowl material |
Polycarbonate |
Filter Drain Storage Volume (mL) |
80 |
