| Model No | R-02B |
| Type of Product | Regulator |
| Material | Zinc alloy |
| Monotaro ID | 34571415 |
Model No |
R-02B |
Type of Product |
Regulator |
Material |
Zinc alloy |
Monotaro ID |
34571415 |
Operating Temperature Range |
5 to 60°C |
Suitable Fluid |
Compressed air |
Country of Origin |
TAIWAN |
Name of Manufacturer/Packer/Importer |
MonotaRO |
Import Country |
Direct Import from Japan |
Pipe Connection Diameter |
Rc1/4 |
Pressure Gauge Connection Size |
R1/8 |
Maximum Operating Pressure (MPa) |
1 |
Maximum Flow Rate (LPM) |
2500 |
LID Material |
Polyacetal |
Thread Type |
Rc |
Assured Pressure Resistance (MPa) |
1.2 |
Pressure Setting Range |
0.05 to 0.85 Mpa |
Pressure Gauge |
With pressure gauge |
Type of Sign |
With bracket |
