Ships within 19 days
Model No
View
View
View
View
| Mass (g) | About 85 g |
| Terminal Shape | Plug-In Terminal |
| Operating Temperature Range | -10~40°C (No Condensation or Freezing) |
| Contact Configuration | 2c |
Mass (g) |
About 85 g |
Terminal Shape |
Plug-In Terminal |
Operating Temperature Range |
-10~40°C (No Condensation or Freezing) |
Contact Configuration |
2c |
Rated Voltage (V) |
AC24 |
Contact Resistance |
50 mΩ or less (DC5 V 1 A Voltage Drop Method) |
No. of Pole |
2 Pole |
Power Consumption |
About 2.2 to 2.7 (60 Hz) |
Insulation Resistance |
100 mΩ or more (Measured with the DC500 V Insulation Resistance Meter at the Same Location as the Withstand Voltage) |
Monotaro ID |
46687392 |
Type of Product |
Small Power Relay |
Model No |
MK2PN-AC24 |
Series |
MK Series |
Classification |
Built-In Operation Indicator |
Operation Ambient Temperature |
-10°C to +40°C (With No Icing or Condensation) |
Shape |
In a Case |
Protection Class |
In a Case |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
10 to 55°C to 10 Hz, Single Amplitude 0.75 mm (Double Amplitude 1.5 mm) |
Operation Indicator |
Pilot Lamp |
With or Without Diode |
None |
Terminal Structure |
Plug-In Terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
