Ships within 19 days
Model No
View
View
View
View
| Mass (g) | About 70 |
| Terminal Shape | Plug-in Terminals |
| CR Circuit | None |
| Operating Temperature Range | -25 to 40℃ |
Mass (g) |
About 70 |
Terminal Shape |
Plug-in Terminals |
CR Circuit |
None |
Operating Temperature Range |
-25 to 40℃ |
Contact Configuration |
4C |
Type |
Bi-Power Relay |
No. of Pole |
4 Pole |
Power Consumption |
About 1.5 |
Monotaro ID |
35080814 |
Type of Product |
Bi-Power Relay |
Model No |
LY4N DC12 |
Shock Resistance |
1000m/s² |
Classification |
Standard type |
Shape |
LY4N |
Protection Class |
In a case |
Coil Voltage |
DC12 V |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Outer Dimensions |
41.5 x42.4 x28 mm or less |
Operation Indicator |
LED |
With or Without Diode |
None |
No. Of Pin |
14 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25 to 40 (with no icing or condensation) <br> -25 to 55 ° C when current is 4A or less |
Manufacturer Part Number |
LY4N DC12 |
Contact Resistance (ohm) |
50 or less, DC5V 1A, based on voltage drop method. |
Insulation Resistance (MOhm) |
100 or more, measure the same points as for the withstand voltage section with a DC500V insulation resistance tester. |
