| Model No | MB6M-E3/45 |
| Mounting Type | Through Hole |
| Type of Product | Bridge Rectifier |
| Minimum Operating Temperature | -55 °C |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
MB6M-E3/45 |
Mounting Type |
Through Hole |
Type of Product |
Bridge Rectifier |
Minimum Operating Temperature |
-55 °C |
Configuration |
Single |
Dimension |
4.83 x 4.1 x 2.7 mm |
Country of Origin |
China |
Name of Manufacturer/Packer/Importer |
RS Components & Controls Ltd |
Package Type |
MBM |
Pin Count |
4 |
Maximum Operating Temperature |
+150 °C |
Height |
2.7 mm |
Length |
4.83 mm |
Width |
4.1 mm |
Peak Non-Repetitive Forward Surge Current |
35 Amp |
Peak Reverse Repetitive Voltage |
600 V |
Bridge Type |
Single Phase |
Peak Reverse Current |
100 µA |
Peak Average Forward Current |
800 mA |
Peak Forward Voltage |
1 V |
