Ships within 19 days
Model No
View
View
View
View
| Type | Incremental Type |
| Model No | E6A2-CS5C 10P/R 0.5M |
| Resolution | 10 Pulses / Rotation |
| Type of Product | Rotary Encoder |
Type |
Incremental Type |
Model No |
E6A2-CS5C 10P/R 0.5M |
Resolution |
10 Pulses / Rotation |
Type of Product |
Rotary Encoder |
Output |
Open Collector Output |
Cable Length |
500 mm |
Output Type |
NPN Open Collector Output |
Connection Type |
Cord Pull-Out Type (Cord Length 0.5 m) |
Case Material |
Aluminum Alloy |
Cable Length (m) |
0.5 m |
Monotaro ID |
8586444 |
Mass (g) |
Approx. 35 (Packed) |
Import Country |
Direct Import from Japan |
Included Components |
Coupling, hexagon spanner, instruction manual |
Main Unit Material |
Aluminum |
Protection Class |
IEC standard IP50 , There is no protection against water and oil. |
Series |
E6A2-C Series |
Material |
Shaft: Sus420J2 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Power Supply Voltage (V) |
DC 12-10% to 24+15% Ripple (pp) 5% or less |
Maximum Rotation Speed |
5000 RPM |
Classification |
Incremental Form |
Withstand Voltage |
500 VAC 50/60 Hz For 1 min Between Current-Carrying Parts And Case |
Power Consumption |
20 mA or less |
