Ships within 19 days
Model No
View
View
View
View
| Return Function | Manual |
| Contact Configuration | 2C |
| Mechanical Durability | 250,000 times or more |
| Protection Class | IP65 |
Return Function |
Manual |
Contact Configuration |
2C |
Mechanical Durability |
250,000 times or more |
Protection Class |
IP65 |
Monotaro ID |
46494341 |
Storage Temperature |
-25 To 65 ℃ (No Freezing Or Condensation) |
Type of Product |
Knob-Type Selector Switch (Round Type) |
Type |
Knob-type selector switch (separate type) |
Operation Type |
selector |
Model No |
A165S-T3M-2S |
Series |
A165S Series |
Light Source |
Non-illuminated |
Country of Origin |
Japan |
Terminal Type |
Quick connector |
Import Country |
Direct Import from Japan |
Number of Notches |
3 |
Type of Illumination |
Non-illuminated |
Rated Voltage (V) |
Switch section: AC 125/AC 250/DC 30 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Contact Resistance (ohm) |
100 mΩ or Less (initial value) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Safety Standard |
Ul(File No. E41515), Csa(File No. Lr45258) |
Specifications |
Confirm Delivery Date Each Time |
