| Type of Product | Duct Particulate Matter Sensor |
| Model No | AI-PM (Duct) |
| Enclosure | Duct Mounting Type IP54 Rating compliant ABS Plastic Body with duct clamp |
| Country of Origin | India |
Type of Product |
Duct Particulate Matter Sensor |
Model No |
AI-PM (Duct) |
Enclosure |
Duct Mounting Type IP54 Rating compliant ABS Plastic Body with duct clamp |
Country of Origin |
India |
Mounting |
Duct mounting type ABS enclosure with adjustable clamp |
Name of Manufacturer/Packer/Importer |
INSTRUKART HOLDING |
Working Life |
Sensor 5 years @ 10–35 °C & 40–80% R.H. for general applications |
Analog Output |
4-20 mA/0-10 VDC (field selectable) |
Measure Range |
0–1000 µg/m³ |
Modbus |
Communication RS485 Modbus |
Measuring Principle |
Laser scattering based sensor for reliable particulate matter detection |
Switch On Behaviour |
Time until reliably detecting Stable PM Reading < 60 seconds |
Power Supply |
24 VDC / 350 mA |
Accuracy |
±15 µg/m³ (when concentration is <100 µg/m³), ±15% (when concentration is >100 µg/m³) |
