| Protection Class | IEC Standard IP67 |
| Type of Product | Proximity Sensor |
| Model No | E2E-X2D1-M1G |
| Size | M8 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Protection Class |
IEC Standard IP67 |
Type of Product |
Proximity Sensor |
Model No |
E2E-X2D1-M1G |
Size |
M8 |
Country of Origin |
CHINA |
Type |
Shield |
Detection Distance |
2 mm ±10% |
Head Shape |
Screw |
Monotaro ID |
39045562 |
Case Material |
Stainless Steel (SUS303) |
Included Components |
Instruction Manual, Tightening Nut, Washer With Teeth |
Connection Type |
M12 Connector Type (IEC Pin Wiring) |
Power Supply Voltage |
DC 12-24 V Ripple (PP) 10% or Less (DC 10-30 V), Class 2 |
Control Output |
Switching Capacity: 3~100 mA, Residual Voltage: 3 V or Less (Load Current: 100 mA, Cord Length: 2 m) |
Withstand Voltage |
Between Live Parts and Case: AC 1000 (50/60 Hz) |
Standard Sensing Object (mm) |
Iron 8x8x1 mm |
Detection Distance (mm) |
2±10% |
Material |
Tightening Nut: Brass Nickel Plated Toothed Washer: Iron Galvanized |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Shape |
Cylindrical (with Screws) |
Body Size |
Standard |
Mass (g) |
Approx. 40 g (Packed) |
