Spacer Length
Coupling Size
View
View
View
View
| Product Sub Type | SWQ |
| FB KW Per Coupling H7 JS9 | 459 |
| D.B.Per CPLG. 6.3 | 649 |
| Hub Type | SWQ Type |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Product Sub Type |
SWQ |
FB KW Per Coupling H7 JS9 |
459 |
D.B.Per CPLG. 6.3 |
649 |
Hub Type |
SWQ Type |
Size |
SWQ-226 |
KW At 100 RPM |
3.43 kW |
Maximum Bore (mm) |
70 mm |
Torque (Nm) |
327 Nm |
Features |
• Spacer type coupling using snapwrap/T-cushions as flexible elements. • Individual replacement of T cushion reduces replacement cost. • Used where rapid disconnection without disturbing the drive or driven unit is required. |
Type of Product |
Jaw Flex Coupling |
Application |
Power Transmission In Rotating Machinery |
Spacer Length |
180 mm |
Coupling Size |
SWQ-226 |
Approx. Weight (Kg) |
26.00 Kg |
Adapter Diameter (mm) |
134mm |
Length Thru Bore |
50mm |
Minimum Bolt Clearance |
92mm |
Bore |
70 mm |
Coupling Type |
SWQ Type Jaw Flex Coupling |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Global bearing & Mill stores |
Suitable For |
Pumps, Compressors, Blowers & Fans, Mixers and Agitators, Conveyors and General industrial machinery |
