Ships within 19 days
Model No
View
View
View
View
| Type | Solid state/relay |
| Model No | G3TA-IAZR02S-US-AC100-240 |
| Mass (g) | About 16 |
| Voltage Drop when Output Turned ON | 1.6 V or less |
Type |
Solid state/relay |
Model No |
G3TA-IAZR02S-US-AC100-240 |
Mass (g) |
About 16 |
Voltage Drop when Output Turned ON |
1.6 V or less |
Insulation Type |
Photo coupler |
Operation Indicator Lamp |
Included |
Operating Voltage Range (V) |
AC 80 to 264 |
Monotaro ID |
46594676 |
Type of Product |
I/O Solid State Relay |
Case Color |
Red |
Output Current (mA) |
25 or less load current: 0.1 to 25 |
Module |
Input module |
Series |
G3TA Series |
Storage Temperature Range |
-30 to +100℃ |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Terminal Structure |
Plug-In Terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Rated Input Voltage (V) |
AC 100 to 240 |
Operation Ambient Temperature (°C) |
-30 to +80 |
Specifications |
UL, CSA standard certified product |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
