Ships within 19 days
Model No
View
View
View
View
| Type | Solid state/relay |
| Model No | G3TA-OA202SL-US-DC12 |
| Load Voltage | AC 75 to 264 V |
| Mass (g) | About 23 |
Type |
Solid state/relay |
Model No |
G3TA-OA202SL-US-DC12 |
Load Voltage |
AC 75 to 264 V |
Mass (g) |
About 23 |
Voltage Drop when Output Turned ON |
1.6 V (RMS) or less |
Rated Load Voltage (V) |
AC 100 to 240 |
Insulation Type |
Photo triac |
Operation Indicator Lamp |
Included |
Equipped with/without Zero Cross Function |
None |
Input Impedance |
0.9k±20% Ω |
Suitable Load of Output |
2 Amp AC 100 to 240 V |
Monotaro ID |
46594737 |
Type of Product |
I/O Solid State Relay |
Case Color |
Black |
Module |
Output module |
Series |
G3TA Series |
Storage Temperature Range |
-30 to +100 ℃ (with no icing or condensation) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Terminal Structure |
Plug-In Terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Rated Input Voltage (V) |
DC 12 |
Operation Ambient Temperature (°C) |
-30 to +80 (with no icing or condensation) |
Specifications |
UL, CSA standard certified product |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
