Ships within 19 days
Model No
View
View
View
View
| Model No | G3PA-260B-VD DC5-24 |
| Load Voltage | AC19~264(50/60Hz) |
| Mass (g) | About 900 g |
| Rated Load Voltage (V) | AC24~240 (50/60 Hz) |
Model No |
G3PA-260B-VD DC5-24 |
Load Voltage |
AC19~264(50/60Hz) |
Mass (g) |
About 900 g |
Rated Load Voltage (V) |
AC24~240 (50/60 Hz) |
Operation Ambient Temperature |
-30°C to 80°C (With No Icing or Condensation) |
Insulation Type |
Photo Triac Coupler |
Insulation Resistance |
100 mΩ or more (with DC 500 V Mega) |
Equipped with/without Zero Cross Function |
Included |
Rated Voltage (V) |
DC5~24 |
Ambient Humidity to Use |
45~85%RH |
Suitable Load of Output |
60 A, AC24 V~240 V |
Monotaro ID |
8589086 |
Type of Product |
Power Solid State Relay |
Operating Temperature Range |
-30 to 80°C (No Condensation or Freezing) |
Standard |
UL508, CSA22.2 No.14, EN60950-1 |
Series |
G3PA Series |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Withstand Voltage |
AC4000 V/min 50/60 Hz |
Terminal Structure |
Screw Terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Applicable Voltage (V) |
DC4~30 V |
Rated Input Voltage (V) |
DC5~24 |
Storage Temperature |
-30 to +100°C (No Condensation or Freezing) |
