Ships within 19 days
Model No
View
View
View
View
| Type | Solid state/relay |
| Model No | G3PA-240B-VD DC5-24 |
| Load Voltage | AC19-264 V (50/60 Hz) |
| Mass (g) | About 460 g |
Type |
Solid state/relay |
Model No |
G3PA-240B-VD DC5-24 |
Load Voltage |
AC19-264 V (50/60 Hz) |
Mass (g) |
About 460 g |
Voltage Drop when Output Turned ON |
1.6 V (RMS) or less |
Rated Load Voltage (V) |
AC 24-240(50/60 Hz) V |
Shock Resistance |
300 m/s (DIN rail mounting) |
Operation Ambient Temperature |
-30 to 80℃ (with no icing or condensation) |
Insulation Type |
Photo triac coupler |
Insulation Resistance |
100 MΩ or more (with DC500V mega) |
Operating Time (ms) |
1/2 cycle of load power supply + 1 or less |
Return Voltage |
DC 1 V or more |
Operating Voltage Range (V) |
DC 4-30 V |
Rated Voltage (V) |
DC 5-24 V |
Ambient Humidity to Use |
45-85%RH |
Leakage Current (mA) |
10 or less (at 100 VAC) <br> 20 or less (at 200 VAC) |
Suitable Load of Output |
40 A AC 24-240 V |
Monotaro ID |
8589077 |
Operating Voltage |
DC 4 V or less |
Type of Product |
Power Solid State Relay |
Standard |
UL508 CSA22.2 No.14 EN60950-1 |
Series |
G3PA Series |
Storage Temperature Range |
-30 to +100℃ (with no icing or condensation) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Zero Cross Function |
Included |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
