| Model No | DCO SD2 E 24 |
| Color | Yellow |
| Application | For 24V supply with load current of 10A |
| Type of Product | Surge Arrester Terminal Block |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
DCO SD2 E 24 |
Color |
Yellow |
Application |
For 24V supply with load current of 10A |
Type of Product |
Surge Arrester Terminal Block |
Pole |
2 Pole |
Part No |
917988 |
Weight |
25 g |
Nominal Current |
10 A @60°C |
Nominal Voltage |
24 V |
Country of Origin |
Germany |
Cross-Sectional Area |
0.34-2.5 mm² (Solid/Fine Stranded) |
Name of Manufacturer/Packer/Importer |
HSV Technologies LLP |
Operating Temperature Range |
-40°C to +80°C |
Capacitance |
Line-Line: ≤ 0.55 nF, Line-PG: ≤ 1.1 nF |
Test Standard |
IEC 61643-21 / EN 61643-21 |
Protection Degree |
IP20 |
Approvals |
UL 497B, CSA, SIL |
Connection |
Input/Output: Spring / Spring |
Cut-off Frequency |
Line-PG: 5.5 MHz |
Voltage Protection Level |
[For In C1 (Uᴩ)] Line-Line: ≤ 96 V, Line-PG: ≤ 48 V | [At 1 kV/µs C3 (Uᴩ)] Line-Line: ≤ 76 V, Line-PG: ≤ 38 V |
Technology |
Gas Discharge Tube |
Enclosure Material |
Polyamide PA 6.6 |
Nominal discharge current (8 / 20μs) (kA) |
[C1] Total: 0.6 kA | Per Line: 0.3 kA |
SPD Class |
Type 2 [P1] |
Maximum Continuous Operating Voltage |
DC: 28 V, AC: 19.5 V |
