DEHN Surge Arrester Terminal Block Yellow 2 Pole 24 V Nominal Voltage 0.5 A Nominal Current, DCO SD2 ME 24

Name: DEHN Surge Arrester Terminal Block Yellow 2 Pole 24 V Nominal Voltage 0.5 A Nominal Current, DCO SD2 ME 24
Brand: DEHN
SKU: IND.TER.636286555
Price: 3303 INR
Availability: InStock

Visit the DEHN Store

EMI starts at ₹293/month. No Cost EMI available.

Available offers

Flat ₹200 off on Order above ₹7,000 | Valid for NEW Business Users

View

Flat ₹100 off on Order above ₹5000 | Valid for NEW Business Users

View

Flat ₹400 off on Order above ₹10,000 | Valid for REPEAT Business User

View

Flat ₹800 off on Order above ₹20,000 | Valid for REPEAT Business User

View

Features

Model No	DCO SD2 ME 24
Color	Yellow
Application	24V DC, Din Rail, Analogue+Digital Signal
Type of Product	Surge Arrester Terminal Block

More DEHN Terminal Block and Accessories products More Terminal Block and Accessories products

Warranty as per brand

100% Original Products

Secure payments

100% Buyer protection

Top Brands

specifications

description

Model No	DCO SD2 ME 24
Color	Yellow
Application	24V DC, Din Rail, Analogue+Digital Signal
Type of Product	Surge Arrester Terminal Block
Pole	2 Pole
Part No	917921
Weight	31 g
Nominal Current	0.5 A @80°C
Nominal Voltage	24 V
Country of Origin	Germany
Cross-Sectional Area	0.34-2.5 mm² (Solid/Fine Stranded)
Name of Manufacturer/Packer/Importer	HSV Technologies LLP
Operating Temperature Range	-40°C to +80°C
Capacitance	Line-Line: ≤ 0.5 nF, Line-PG: ≤ 1 nF
ATEX Approval	DEKRA 17ATEX0046 X: II 3 G Ex ec IIC T6...T4 Gc
Test Standard	IEC 61643-21 / EN 61643-21
Protection Degree	IP00
Approvals	UL 497B, CSA, SIL, ATEX, IECEx \| IECEx: DEK 17.0023X: Ex ec IIC T6...T4 Gc
Connection	Input/Output: Spring / Spring
Cut-off Frequency	Line-PG: 6 MHz
Voltage Protection Level	[For In C2 (Uᴩ)] Line-Line: ≤ 120 V, Line-PG: ≤ 75 V \| [At 1 kV/µs C3 (Uᴩ)] Line-Line: ≤ 90 V, Line-PG: ≤ 45 V
Technology	Gas Discharge Tube
Series Resistance	Per Line: 1.8 Ω
Enclosure Material	Polyamide PA 6.6
Nominal discharge current (8 / 20μs) (kA)	[C2] Total: 10 kA \| Per Line: 5 kA
Maximum Discharge Current	20 kA [8/20 µs (1/2 - PG), (1+2 - PG) (Imax)]
SPD Class	Type 2 [P1]
Maximum Continuous Operating Voltage	DC: 33 V, AC: 23 V
Lightning Impulse Current (10/350 µs) Per Line	[D1] 1 kA
