Ships within 90 days
Nameplate RPM
Power
View
View
View
View
| Mounting Type | Rigid Base |
| Rated Voltage | 208-230/460V AC |
| Phase | Three |
| Type of Product | General Purpose Motor |
Mounting Type |
Rigid Base |
Rated Voltage |
208-230/460V AC |
Phase |
Three |
Type of Product |
General Purpose Motor |
Pole |
- |
Power |
1 HP |
Standard |
CE CSA (264511) UL (E47479) |
Frame |
182/4 |
Class |
F |
Item Code |
2N933 |
Frame Material |
Steel |
Country of Origin |
Mexico |
Duty Cycle |
Continuous |
Shaft Diameter |
7/8 inch |
Thermal Protection |
None |
Enclosure Design |
Totally Enclosed Fan-Cooled |
Overall Length |
15-1/4 inch |
Shaft rotation |
CW/CCW |
Inverter Rated Watts |
Yes |
UNSPSC Code |
26101612 |
Length Less Shaft |
13-9/16 inch |
Shaft Length |
2-1/4 inch |
Full Load (Amps) |
3.4/1.7 A |
Max. Ambient Temp. (F) |
104 °F |
Part No |
2N933 |
No. Of Speeds |
1 |
Motor Design |
3-Phase |
Motor Shaft Design |
Keyed |
Nominal Efficiency |
85.5 % |
RPM Range |
1,701-1,800 |
Motor Service Factor |
1.15 |
Motor Bearings |
Ball |
Motor Application |
General Application |
CC Number |
CC029A |
Hz |
60 Hz |
Manufacturer Part Number |
2N933 |
Nameplate Speed |
1,760 |
Nameplate RPM |
1760 RPM |
Length (mm) |
344.5 mm |
Overall Length (cm) |
38.74 cm |
Shaft Diameter (mm) |
22.22 mm |
Shaft Length (mm) |
57.15 mm |
