Ships within 90 days
Nameplate RPM
Power
View
View
View
View
| Mounting Type | Rigid Base |
| Rated Voltage | 230/460V AC |
| Phase | Three |
| Type of Product | General Purpose Motor |
Mounting Type |
Rigid Base |
Rated Voltage |
230/460V AC |
Phase |
Three |
Type of Product |
General Purpose Motor |
Pole |
- |
Power |
2 HP |
Standard |
CE CSA UL |
Frame |
145T |
Class |
F |
Item Code |
2MXT9 |
Frame Material |
Cast Iron |
Country of Origin |
Varies |
Duty Cycle |
Continuous |
Shaft Diameter |
7/8 inch |
Thermal Protection |
None |
Enclosure Design |
Totally Enclosed Fan-Cooled |
Overall Length |
13-5/16 inch |
Shaft rotation |
CW/CCW |
Inverter Rated Watts |
Yes |
UNSPSC Code |
26101612 |
Length Less Shaft |
11-15/16 inch |
Shaft Length |
2-1/4 inch |
Full Load (Amps) |
5.0/2.5 A |
Max. Ambient Temp. (F) |
104 °F |
Part No |
194178 |
No. Of Speeds |
1 |
Motor Design |
3-Phase |
Motor Shaft Design |
Keyed |
Motor Mounting Position |
Horizontal |
Nominal Efficiency |
85.5 % |
RPM Range |
3,001-3,600 |
Motor Service Factor |
1.15 |
Motor Bearings |
Ball |
Motor Application |
General Application |
CC Number |
CC003A |
Hz |
60 Hz |
Manufacturer Part Number |
194178.00 |
Nameplate Speed |
3,480 |
Nameplate RPM |
3480 RPM |
Length (mm) |
303.2 mm |
Overall Length (cm) |
33.81 cm |
Shaft Diameter (mm) |
22.22 mm |
Shaft Length (mm) |
57.15 mm |
