| Type of Product | Thyristor |
| Model No | ST330S16P1PBF |
| Dimension | 49 x 42.5 x 74.5 mm |
| Country of Origin | USA |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Thyristor |
Model No |
ST330S16P1PBF |
Dimension |
49 x 42.5 x 74.5 mm |
Country of Origin |
USA |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Product Code |
3959315 |
Maximum Holding Current |
600 mA |
Repetitive Peak Off-State Current |
50 mA |
Rated Average On-State Current |
330 Amp |
Thyristor Type |
SCR |
Repetitive Peak Reverse Voltage |
1600 V |
Repetitive Peak Forward Blocking Voltage |
1600 V |
Maximum Gate Trigger Voltage |
3 V |
Surge Current Rating |
9420 Amp |
Peak On-State Voltage |
1.52 V |
Maximum Operating Temperature |
+125 °C |
Maximum Gate Trigger Current |
200 mA |
Operating Temperature |
-40 °C |
Package Type |
TO-118 |
Mounting Type |
Stud |
Pin Count |
3 |
