| Diameter | Φ40 mm |
| Model No | LR4-302WJNW-RYG |
| Flash Rate | 60 ±2 Flashes / min. |
| Type of Product | Signal Tower Light |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Diameter |
Φ40 mm |
Model No |
LR4-302WJNW-RYG |
Flash Rate |
60 ±2 Flashes / min. |
Type of Product |
Signal Tower Light |
Protection |
IP65(IEC 60529) / NEMA TYPE 4X, 13 |
Country of Origin |
Japan |
Sound Level |
LR4 Typ. 85dB |
Name of Manufacturer/Packer/Importer |
Patlite |
Mounting Type |
Indoor Use, Upright Position |
Operating Humidity Range |
90% RH or less, no condensation |
Storage Temperature Range |
-30℃ - +60℃ |
Operating Ambient Temperature |
-20℃ - +50℃ |
Withstand Voltage |
AC 500V for 1 minute between terminals and chassis without breaking insulation (M2: AC1500V for 1 min.) |
Sound Reduction |
Approx. -10dB reduction |
Conformity |
● UL 508, CSA-C22.2 No.14 ● FCC Part 15 Subpart B Class A ● RoHS Directive (EN IEC 63000) ● EMC Directive (EN 61000-6-4, EN 61000-6-2) ● KC (KN 61000-6-4, KN 61000-6-2)*3 ● Low-voltage Directive (IEC/EN 60947-5-1, EN62471)*4 |
