Ships within 25 days
View
View
View
View
| Type | Stacked signal lights |
| Model No | LR4-302LJNW-GBC |
| Light Source | LED |
| Protection Class | IP54 |
Type |
Stacked signal lights |
Model No |
LR4-302LJNW-GBC |
Light Source |
LED |
Protection Class |
IP54 |
Type of Product |
Stacked Signal Light Signal Tower |
Material |
PC |
Country of Origin |
Japan |
LED Color |
Green-Blue-White |
Name of Manufacturer/Packer/Importer |
Patlite Corporation |
Height (mm) |
219 (excluding cab-tyre cables and poles) |
No. of Tiers |
3 |
Import Country |
Direct Import from Japan |
Monotaro ID |
40679976 |
Rated Voltage (V) |
DC 24 |
Connection Method |
Cab tire cord |
Action Type |
Lights on, no flashing, no buzzer |
Power Consumption (W) |
3.9 |
Outer Diameter (Φmm) |
40 |
Rated Power Consumption (W) |
[Standard] LED unit of each color: 1, buzzer unit: 1, [Maximum] LED unit of each color: 1.3, buzzer unit: 1.3 |
Mass (Kg) |
0.56499999999999995 |
Conform to |
NPN/PNP |
Applicable Standard |
UL508, CSA-C22.2 No.14, EMC Directive (EN 61000-6-4, EN 61000-6-2), RoHS Directive (EN 50581), KC (KN 61000-6-4, KN 61000-6-2), FCC Part15 SubpartB Class A |
Type of Sign |
Pole mounting + L angle |
Location |
Indoor |
Looking for bulk pricing or different specifications?
