| Material | Steel |
| Type of Product | Super Torque Timing Pulley |
| Model No | P28-S14M-0400A |
| Shape | A Type |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Material |
Steel |
Type of Product |
Super Torque Timing Pulley |
Model No |
P28-S14M-0400A |
Shape |
A Type |
Country of Origin |
Japan |
Nominal Width (mm) |
400 mm |
Product Type |
Timing Pulley |
Dimension LA (mm) |
53 mm |
Monotaro ID |
35271162 |
Outer Diameter (Φmm) |
121.98 mm |
Pitch Diameter (Φmm) |
124.78 mm |
Shaft Hole Diameter d (mm) |
(min) 25 mm / (max) 56 mm |
Suitable Flange |
F-23136101 |
Suitable Belt Width (mm) |
40 mm |
Compatible Belt |
S14M |
Tooth width W (mm) |
78 mm |
No. of Teeth |
28 |
Dimension H |
3.5 mm |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
