| Material | Steel |
| Type of Product | Super Torque Timing Pulley |
| Model No | 44S14M600B |
| Shape | B Type |
Material |
Steel |
Type of Product |
Super Torque Timing Pulley |
Model No |
44S14M600B |
Shape |
B Type |
Country of Origin |
Japan |
Product Type |
Timing Pulley |
Dimension LA (mm) |
74 mm |
Monotaro ID |
47901621 |
Pitch Diameter (Φmm) |
196.08 mm |
Shaft Hole Diameter d (mm) |
30 mm |
Suitable Flange |
F-23208173 |
Compatible Belt |
S14M |
No. of Teeth |
44 |
Dimension H |
3.5 mm |
Dimension LB (mm) |
99 mm |
Dimension K |
25 mm |
Nominal Width |
60 mm |
Mass |
19.37 Kg |
Maximum shaft hole diameter d (Φmm) |
90 mm |
Dimension W |
67 mm |
Applicable flange outer diameter D (mm) |
208 mm |
Tooth Type |
S14M |
Cell Spacing (mm) |
14 mm |
Dimension d |
155 mm |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
