Schneider 1 NO + 1 NC Red Emergency Switching Off Mushroom Head push button, XB5AS8445N

Product Specifications:

• Device short name: XB5
• Bezel material: Dark grey plastic
• Fixing collar material: Plastic
• Head type: Standard
• Mounting diameter: 22 mm
• Sale per indivisible quantity: 1
• Shape of signaling unit head: Round
• Type of operator: Trigger action and mechanical latching
• Reset: Turn to release
• Operator profile: Red mushroom Ø 40 mm, unmarked
• Contact operation: Slow-break
• Terminals description ISO n°1: (11-12)NC, (13-14)NO
• Resistance to high pressure washer: 7000000 Pa at 55 °C, distance : 0.1 m
• Contacts usage: Standard contacts
• Positive opening: With conforming to EN/IEC 60947-5-1 appendix K
• Mechanical durability: 300000 cycles
• Tightening torque: 0.8…1.2 N.m conforming to EN 60947-1
• Contacts material: Silver alloy (Ag/Ni)
• Short-circuit protection: 10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1
• [Ith] Conventional free air thermal current: 10 A conforming to EN/IEC 60947-5-1
• [Ui] Rated insulation voltage: 600 V (pollution degree 3) conforming to EN 60947-1
• [Uimp] Rated impulse withstand voltage: 6 kV conforming to EN 60947-1
• Protective treatment: TH
• Ambient air temperature for storage: -40…70 °C
• Ambient air temperature for operation: -40…70 °C
• IK degree of protection: IK03 conforming to IEC 50102
• Product certifications: CSA, GL, LROS (Lloyds register of shipping), BV,
• Vibration resistance: 5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
• Shock resistance:

1. 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
2. 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
