Ships within 19 days
Rated Input (W) (50 / 60Hz)
Model No
View
View
View
View
| Rated Input (W) (50 / 60Hz) | 3.6 W |
| Rated Speed (rpm) | 3550 RPM |
| Rated current (A) (50 / 60Hz) | 0.15 A |
| Maximum Static Pressure (Pa) | 56.1 |
Rated Input (W) (50 / 60Hz) |
3.6 W |
Rated Speed (rpm) |
3550 RPM |
Rated current (A) (50 / 60Hz) |
0.15 A |
Maximum Static Pressure (Pa) |
56.1 |
Rotational Speed |
High Speed |
Type |
DC |
Monotaro ID |
63701777 |
Sound Pressure Level (dB) |
39 |
Type of Product |
DC Axial Fan |
Model No |
R89F-DS0925H-S2 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Maximum Airflow |
1.66 m³ |
Set Contents |
Fan body, finger guardx2, M4 screw (40 mm)x4 & nut setx4 |
Speed |
high speed |
Rated Current (A) |
0.15 |
Part No |
64-9683-35 |
Rated Voltage (V) |
DC 24 |
Voltage Fluctuation Tolerance |
12 to 27.6V |
Size (mm) |
□92x25 |
Rated Rotation Speed (min⁻¹ [rpm]) |
3550 |
Pack of |
1 Pcs |
Rated input (W) |
3.6 |
