| Size (mm) | 50 mm |
| Color | Silver |
| Type of Product | Ball Valve |
| Size (Inch) | 2 inch |
Size (mm) |
50 mm |
Color |
Silver |
Type of Product |
Ball Valve |
Size (Inch) |
2 inch |
Type |
Two Piece Design Lever Operated |
Country of Origin |
India |
Standard |
BS EN ISO 17292/API 6D |
Port Opening |
Full Bore |
Body Material |
Cast Stainless Steel |
Rating |
Class - 300 |
Stem |
Stainless Steel ASTM A 276 TYPE 304 |
Ball |
Stainless Steel (ASTM A 351 Gr. CF8) Seat Ring & Gland Packing RPTFE |
Pressure |
B.T.P. - 76 Bar Hyd, S.T.P.-55 Bar Hyd |
Model No |
CF8 023 |
Seat |
Renewable Seat |
End Connection Type |
Flanges as per ASME B 16.5 CL 300 RF Drilled |
Material Standard |
ASTM A 351 Gr.CF8 |
Size Code |
J |
Name of Manufacturer/Packer/Importer |
Industrial Engineering Syndicate |
Air Pressure |
6.9 Bar (AIR) |
