Ships within 8 days
View
View
View
View
| Size (mm) | 80 mm |
| Color | Silver |
| Type of Product | Ball Valve |
| Size (Inch) | 3 inch |
Size (mm) |
80 mm |
Color |
Silver |
Type of Product |
Ball Valve |
Size (Inch) |
3 inch |
Type |
Two Piece Design Lever Operated |
Country of Origin |
India |
Standard |
BS EN ISO 17292 / API 6D |
Port Opening |
Full Bore |
Body Material |
Cast Stainless Steel |
Rating |
Class - 600 |
Stem |
Stainless Steel ASTM A 276 TYPE 316 |
Ball |
Stainless Steel (ASTM A 351 Gr. CF8M) Seat Ring & Gland Packing RPTFE |
Pressure |
B.T.P. - 150 Bar Hyd, S.T.P-76 Bar Hyd |
Model No |
CF8M027 |
Seat |
Renewable Seat |
End Connection Type |
Flanges as per ASME B 16.5 CL 600 RF Drilled |
Material Standard |
ASTM A 351 CF8M |
Size Code |
L |
Name of Manufacturer/Packer/Importer |
Industrial Engineering Syndicate |
Air Pressure |
6.9 Bar (AIR) |
