Showing 19 out of 19 products
Type of Product : Seated Gate/Sluice Valve
Model No : RSV
Seat Test Pressure : 1.6MPa Hyd.
Trim : AISI 420
Body Test Pressure : 2.4MPa Hyd.
Type of Wedge : DI+EPDM
Class : PN 16
End Details : Flanges as per IS-1538 R/F Drilled
Type of Product : Gate Valve
End Connection Type : Flanges as per ASME B 16.5 Class 150 R.F., undrilled
Model No : CS 7
Seat Test Pressure : 22barg(320Psig.) Hyd. 6.9barg AIR (100Psig.)
Trim : SS AISI-410 with Aluminum Bronze Sleeve
Body Test Pressure : 30barg Hyd. (435 Psig)
Product Standard : Conforming to BS 1414/API-600
Seat Type : Renewable Seat
Class : Class-150
Pattern Type : Straight
Body Material : Cast Steel
Type of Product : Cast Steel Gate Valve
Grade : A-216
Model No : CS 7 B
Seat Test Pressure : 112 Bar g Hyd
Body Test Pressure : 153 Bar g Hyd
Body : Cast Carbon Steel
Type of Product : Wheel Operated Gate Valve
Model No : IS 7
Seat Test Pressure : 40kgf/cm² Hyd.
Trim : Cu-Alloy
Body Test Pressure : 50kgf/cm² Hyd.
Product Standard : IS-778:1971
Type of Wedge : Solid wedge
Seat Type : Integral seat
Class : Class-3
Body Material : Gun Metal
Related Searches
Type of Product : Wheel Operated Gate Valve
Model No : IS 6A
Seat Test Pressure : 1.6MPa Hyd
Trim : Cu-Alloy
Body Test Pressure : 2.4MPa Hyd
Product Standard : IS-778
Type of Wedge : Solid wedge
Seat Type : Integral seat
Class : Class-2
Body Material : Gun Metal
Type of Product : Wheel Operated Gate Valve
Model No : IS 6
Seat Test Pressure : 1.6MPa Hyd
Trim : Cu-Alloy
Body Test Pressure : 2.4MPa Hyd
Product Standard : IS-778
Type of Wedge : Solid wedge
Seat Type : Integral seat
Class : Class-2
Body Material : Gun Metal
Type of Product : Wheel Operated Gate Valve
Model No : IS 5
Seat Test Pressure : 1.6MPa Hyd
Trim : Cu-Alloy
Body Test Pressure : 2.4MPa Hyd
Product Standard : IS-778
Seat Type : Integral seat
Class : Class-2
Body Material : Gun Metal
Type of Product : Wheel Operated Gate Valve
Model No : IS 5A
Seat Test Pressure : 1.6MPa Hyd
Trim : Cu-Alloy
Body Test Pressure : 2.4MPa Hyd
Product Standard : IS-778
Seat Type : Integral seat
Class : Class-2
Body Material : Gun Metal
Type of Product : Wedge Gate Sluice Valve
Model No : CR 19
Seat Test Pressure : 1.0 MPa Hyd
Trim : Cu-Alloy Seats, Stem SS AISI 410
Body Test Pressure : 1.5 MPa Hyd
Product Standard : Face to Face, flange dimensions as per IS-780
Seat Type : Renewable
Class : PN 1.0
End Details : Flanges as per IS-780/IS-1538 FF Drilled
Body Material : Cast Iron
Type of Product : Wedge Gate Sluice Valve
Model No : CR 19B
Seat Test Pressure : 1.6MPa Hyd. (232Psig.) Hyd
Trim : Cu-Alloy Seats, Stem SS AISI 410
Body Test Pressure : 2.4MPa Hyd. (348Psig.) Hyd
Seat Type : Renewable
Class : PN 1.6 PD Type
End Details : Flanges Drilled as per IS-1538 FF Drilled
Body Material : Cast Iron
Type of Product : Wedge Gate Sluice Valve
Model No : CR 19A
Seat Test Pressure : 1.6MPa Hyd. (232 Psig. Hyd.)
Trim : Cu-Alloy Seats, Stem SS AISI 410
Body Test Pressure : 2.4MPa Hyd. (348 Psig. Hyd.)
Seat Type : Renewable
Class : PN 1.6 PD Type
End Details : Flanges as per IS-1538 FF Drilled
Body Material : Cast Iron
Type of Product : Wedge Gate Sluice Valve
Model No : CR 32B
Seat Test Pressure : 1.6 MPa Hyd. (232 Psig)
Trim : Cu-Alloy, Stem SS (12 Cr. 12)
Body Test Pressure : 2.4 MPa Hyd. (348 Psig)
Product Standard : IS-14846 duly ISI Marked
Seat Type : Renewable
Class : PN 1.6 PD Type
End Details : Flanges as per IS 1538 F/F Drilled
Body Material : Cast Iron
Type of Product : Wedge Gate Sluice Valve
Model No : CR 32A
Seat Test Pressure : 1.0 MPa (Hyd.)
Trim : Cu-Alloy, Stem SS AISI-410
Body Test Pressure : 1.5 MPa (Hyd.)
Seat Type : Renewable
Class : PN 1.0 PD Type
End Details : Flanges as per IS 1538 F/F Drilled
Body Material : Cast Iron
Type of Product : Wedge Gate Sluice Valve
Model No : CR 32
Seat Test Pressure : 1.0 MPa Hyd
Trim : Cu-Alloy Rings, stem SS (12 Cr. 12)
Body Test Pressure : 1.5 MPa Hyd.
Product Standard : IS-14846 duly ISI Marked
Seat Type : Renewable
Class : PN 1.0 PD Type
End Details : Flanges as per IS 1538 F/F Drilled
Body Material : Cast Iron
Type of Product : Gate Valve
Model No : CS 7A
Seat Test Pressure : 56barg(815Psig.) Hyd. 6.9barg AIR (100Psig.)
Trim : SS AISI-410 with Aluminum Bronze Sleeve
Body Test Pressure : 76barg Hyd. (1110 Psig)
Product Standard : Conforming to BS 1414/API-600
Seat Type : Renewable Seat
Class : Class-300
Pattern Type : Straight
Body Material : Cast Steel
Type of Product : Wheel Operated Gate Valve
Model No : FSV 1B
Seat Test Pressure : 152 barg (2200Psig) Hyd. (6.9barg(100Psig) AIR
Trim : SS Type 410
Body Test Pressure : 207 barg Hyd. (3000 Psig)
Product Standard : Conforming to BS5352/API 602 Class-800
Seat Type : Renewable Seat
Class : Class-800
Disc Type : Renewable Disc
Body Material : Forged Steel
Type of Product : Wheel Operated Gate Valve
Model No : FSV 1A
Seat Test Pressure : 152 barg (2200Psig) Hyd. (6.9barg(100Psig) AIR
Trim : SS Type 410
Body Test Pressure : 207 barg Hyd. (3000 Psig)
Product Standard : Conforming to BS5352/API 602 Class-800
Seat Type : Renewable Seat
Class : Class-800
Disc Type : Renewable Disc
Body Material : Forged Steel
Type of Product : Wheel Operated Gate Valve
End Connection Type : Screwed
Model No : CI 14
Seat Test Pressure : 14.06kg/cm²g Hyd.
Trim : Cu-Alloy
Body Test Pressure : 21.09kg/cm² Hyd.
Seat Type : Renewable
Pattern Type : Clip Pattern
Disc Type : Solid Wedge
Body Material : Cast Iron
Type of Product : Gate Valve (All Iron)
Model No : CI 13
Seat Test Pressure : 14.06kg/cm²g (200Psig. Hyd.)
Trim : Mild Steel
Body Test Pressure : 21.09kg/cm² Hyd. 300Psig. Hyd.
Seat Type : Integral Seat
Pattern Type : Clip Pattern
End Details : Screwed Female BSP Parallel Threads to BS:21
Disc Type : Solid Wedge
Body Material : Cast Iron
Page 1 of 1 results
| Product Name | Expected Price | Dispatch Time | Discount |
|---|---|---|---|
| Zoloto 20 mm Bronze Hex Type Gate Valve 1006 | ₹1,415 | 7 days | -- |
| Zoloto 40 mm Cast Steel Wheel Operated Gate Valve 1077 | ₹11,799 | 7 days | -- |
| Zoloto 80 mm Flanged Cast Iron Sluice Valve 1079 B | ₹13,637 | 7 days | -- |
| Zoloto 150 mm Flanged Cast Iron Sluice Valve 1079 B | ₹27,139 | 7 days | -- |
| Zoloto 25 mm Bronze Screwed Gate Valve 1035 A | ₹2,813 | 7 days | -- |
| Leader 3 Inch, 80 mm Gun Metal Wheel Operated Gate Valve GM 002 | ₹14,159 | 5 days | 10.84% OFF |
| Leader 1-1/2 Inch, 40 mm Gun Metal Wheel Operated Gate Valve IS 010 | ₹14,159 | 16 days | 3.79% OFF |
| Zoloto 150 mm Flanged Cast Iron Sluice Valve 1079 A | ₹22,419 | 7 days | -- |
