| Type of Product | Proximity Sensor Ultra-Compact Type (DC 2-Wire Type) |
| Model No | E2S-W11 1M |
| Type | Built-in Amplifier |
| Cable Length (m) | 1 m |
Type of Product |
Proximity Sensor Ultra-Compact Type (DC 2-Wire Type) |
Model No |
E2S-W11 1M |
Type |
Built-in Amplifier |
Cable Length (m) |
1 m |
Output |
DC 2-Wire Type |
Case Material |
Polyarylate |
Protection Class |
IEC Standard IP67 |
Ambient Humidity |
Operating & Storage: 35 to 95% RH (No Condensation) |
Connection Type |
Cord drawer type |
Detection Distance |
1.6mm±15% |
Vibration Resistance |
10~55 Hz, 1.5 mm double amplitude, 2 hours each in X, Y, and Z directions |
Protection Circuit |
Power Supply Reverse Connection Protection, Surge Absorption |
Insulation Resistance |
50 MΩ or more (at 500 VDC) between live parts and case |
Cable Length |
1 m |
Switching Capacity |
3-50 mA or Less |
Power Supply Voltage |
DC12 ~ 24 V Ripple (pp) 10% or less |
Monotaro ID |
8586207 |
Sensor Shape |
Rectangular |
Residual voltage (V) |
3V or Less (Load Current 50mA and Cord Length 1m) |
Setting Distance (mm) |
0～1.2 mm |
Head Shape |
Corner |
Influence of Voltage |
± 2.5% or less of sensing distance at rated power voltage within the range of rated power voltage ± 10% |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Standard sensing Object |
Iron: 12 × 12 × 1 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Included Components |
Mounting Bracket |
Operating Voltage Range |
DC10～30 V |
