| Type of Product | DC Gearmotor |
| Maximum Torque | 160 inch-lb |
| Part No | 2H575 |
| Item Code | 2H575 |
Type of Product |
DC Gearmotor |
Maximum Torque |
160 inch-lb |
Part No |
2H575 |
Item Code |
2H575 |
Housing Material |
Aluminum |
Standard |
C-UL Recognized UL Recognized |
Output Shaft Diameter |
5/8 inch |
Motor Type |
Permanent Magnet DC |
Thermal Protection |
None |
Maximum Ambient Temperature |
40 °C |
Lubrication |
Permanent Heavy Fluid Gear Oil |
Gear Ratio |
19:1 |
Operating Voltage |
90 V DC |
Gear Material |
Hardened Steel |
Country of Origin |
USA |
Output Shaft Length |
1-1/2 inch |
Bearing Type |
Ball on Motor Needle Throughout |
UNSPSC Code |
26101603 |
Length Less Shaft |
12.13 inch |
Rotation |
CW/CCW |
Seal Type |
Spring Loaded Lip Type on Input and Output Shaft |
Mounting Orientation |
Any Angle |
Motor Enclosure |
Totally Enclosed Nonventilated |
Shaft Orientation |
Parallel |
Gear Type |
Helical Spur |
Overall Length |
13.63 inch |
Replaceable Brushes |
Yes |
Nameplate Speed |
90 RPM |
Input Horsepower |
1/4 HP |
Overhung Load Capacity |
200 ft-lb |
Full Load |
2.51 A |
Length (mm) |
308.1 mm |
Overall Length (cm) |
34.62 cm |
Maximum Torque (Nm) |
18.08 Nm |
