Ships within 90 days
Maximum Torque
Nameplate Speed
View
View
View
View
| Type of Product | DC Gearmotor |
| Maximum Torque | 100 inch-lb |
| Part No | 6Z911 |
| Item Code | 6Z911 |
Type of Product |
DC Gearmotor |
Maximum Torque |
100 inch-lb |
Part No |
6Z911 |
Item Code |
6Z911 |
Housing Material |
Aluminum |
Standard |
C-UL Recognized UL Recognized |
Output Shaft Diameter |
1/2 inch |
Motor Type |
Permanent Magnet DC |
Thermal Protection |
None |
Maximum Ambient Temperature |
40 °C |
Lubrication |
Permanent Heavy Fluid Gear Oil |
Gear Ratio |
362:1 |
Operating Voltage |
90 V DC |
Gear Material |
Steel (1st Stage Helical) Steel or Heat Treated Powdered Metal (Subsequent Stages Spur) |
Country of Origin |
USA |
Output Shaft Length |
1 inch |
Bearing Type |
Ball on Motor Needle on Case Output Shaft |
UNSPSC Code |
26101603 |
Length Less Shaft |
7.38 inch |
Rotation |
CW/CCW |
Seal Type |
Spring Loaded Lip Type on Input and Output Shaft |
Mounting Orientation |
Any Angle |
Motor Enclosure |
Totally Enclosed Nonventilated |
Shaft Orientation |
Parallel |
Gear Type |
Helical Spur |
Overall Width |
3.63 inch |
Depth |
3/4 inch |
Overall Height |
2.75 Inch |
Overall Length |
8.38 inch |
Replaceable Brushes |
Yes |
Nameplate Speed |
5 RPM |
Input Horsepower |
1/40 HP |
Overhung Load Capacity |
90 ft-lb |
Full Load |
0.36 A |
Length (mm) |
187.5 mm |
Overall Length (cm) |
21.29 cm |
Overall Height (mm) |
69.85 mm |
Overall Width (mm) |
92.2 mm |
Maximum Torque (Nm) |
11.30 Nm |
