| Type of Product | DC Gearmotor |
| Maximum Torque | 50 inch-lb |
| Part No | 1LPW2 |
| Item Code | 1LPW2 |
Type of Product |
DC Gearmotor |
Maximum Torque |
50 inch-lb |
Part No |
1LPW2 |
Item Code |
1LPW2 |
Housing Material |
Die Cast Zinc |
Standard |
C-UL Recognized UL Recognized |
Output Shaft Diameter |
5/16 inch |
Motor Type |
Permanent Magnet DC |
Thermal Protection |
None |
Maximum Ambient Temperature |
40 °C |
Lubrication |
Grease Filled |
Gear Ratio |
141:1 |
Operating Voltage |
90 V DC |
Gear Material |
Acetyl Steel |
Country of Origin |
USA |
Output Shaft Length |
3/4 inch |
Bearing Type |
Ball on Motor Porous Bronze Sleeve on Case |
UNSPSC Code |
20101617 |
Length Less Shaft |
5.63 inch |
Rotation |
CW/CCW |
Seal Type |
O-Ring Type on Output Shaft |
Mounting Orientation |
Any Angle |
Motor Enclosure |
Totally Enclosed Nonventilated |
Shaft Orientation |
Parallel |
Keyway Type |
Flat |
Overall Length |
6.38 inch |
Material Finish |
Unpainted |
Replaceable Brushes |
Yes |
Nameplate Speed |
21 RPM |
Input Horsepower |
1/30 HP |
Overhung Load Capacity |
50 ft-lb |
Full Load |
0.35 A |
Length (mm) |
143 mm |
Overall Length (cm) |
16.21 cm |
Maximum Torque (Nm) |
5.65 Nm |
