| Type | Compact limit switch |
| Country of Origin | JAPAN |
| Shape | General-purpose vertical type |
| Type of Product | Compact Limit Switch |
Type |
Compact limit switch |
Country of Origin |
JAPAN |
Shape |
General-purpose vertical type |
Type of Product |
Compact Limit Switch |
Mechanical Durability |
10 Million Times Or More |
Allowable Operating Speed |
0.1 mm to 0.5M/S |
Protection Class |
IP67 |
Electrical Durability |
200,000 operations or more (125 VAC, 5 A resistance load) |
Actuator Type |
Roller plunger type |
Model No |
D4C-5502 |
Monotaro ID |
46523163 |
Withstand Voltage |
(between terminals of the same polarity), AC 1000 V 50/60 Hz 1min, (between live metal part and earth), AC 1500 V 50/60 Hz 1min/Uimp 2.5 kV(EN60947-5-1), (between each terminal and non-current-carrying metal parts), AC 1500 V 50/60 Hz 1min/Uimp 2.5kV(EN60947-5-1) |
Electric Shock Protection Class |
ClassI (with ground wire) |
Rated Frequency (Hz) |
50/60 |
Short Circuit Protection Device |
10A fuse gI or gG (IEC60269) |
Cable Length (m) |
5 |
Electrical ratings |
AC 125 V 0.1 Amp (with LED indicator light) |
Inrush current (A) |
Normally closed circuit: Up to 20, Normally open circuit: Up to 10 |
Rated Insulation Voltage (V) |
(Ui)300(EN60947-5-1) |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to 70 (no icing) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Remark |
Confirm Delivery Date Each Time |
