| Country of Origin | JAPAN |
| Type of Product | General Limit Switch |
| Mechanical Durability | 10 Million Times Or More |
| Allowable Operating Speed | 0.05 mm to 0.5 m/s |
Country of Origin |
JAPAN |
Type of Product |
General Limit Switch |
Mechanical Durability |
10 Million Times Or More |
Allowable Operating Speed |
0.05 mm to 0.5 m/s |
Protection Class |
IP67 |
Electrical Durability |
500,000 times or more |
Actuator Type |
Hinge / roller / lever type |
Model No |
D4MC-2002VCT3M |
Monotaro ID |
66463048 |
Electric Shock Protection Class |
Class Ⅱ |
Rated Frequency (Hz) |
50/60 |
Cable Length (m) |
3 |
Pollution Degree (Environment to Use) |
3(IEC947-5-1) |
Inrush current (A) |
Normally closed: Maximum 30, Normally open: Maximum 15 |
Rated Insulation Voltage (V) |
1000 AC |
Import Country |
Direct Import from Japan |
Switch Category |
D(IEC335) |
PTI (Proof Tracking Index) |
175 |
Rated Operating Voltage (V) |
AC250 |
Rated Operating Current (A) |
10 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (No Icing) |
Contact Resistance (ohm) |
15 mΩ or less (Initial Value, Built-In Switch Only) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Nominal Sectional Area (mm²) |
1.25 |
