| Type | General type (standard type) |
| Country of Origin | JAPAN |
| Type of Product | 2-Circuit Limit Switch Head |
| Protection | Standard type |
Type |
General type (standard type) |
Country of Origin |
JAPAN |
Type of Product |
2-Circuit Limit Switch Head |
Protection |
Standard type |
Protection Class |
IP67 |
Switch Type |
General built-in switch |
Actuator Type |
Spring rod lever |
Model No |
WLCAL5-G1LD-N |
Monotaro ID |
66526583 |
Mass (g) |
Approximately 255 (for type WLCA2-N) |
Rated Frequency (Hz) |
50/60 |
Rated Insulation Voltage (V) |
(Ui)250(EN60947-5-1) |
Load Connection |
General load / micro load shared |
Import Country |
Direct Import from Japan |
Terminal Shape |
Screw tightening terminal (conduit size G1 / 2) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (No Icing) |
Contact Resistance (ohm) |
25 mΩ or less (initial value, built-in switch only) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
