| Type | General type (standard type) |
| Country of Origin | JAPAN |
| Shape | General-purpose vertical type |
| Type of Product | 2-Circuit Limit Switch Head |
Type |
General type (standard type) |
Country of Origin |
JAPAN |
Shape |
General-purpose vertical type |
Type of Product |
2-Circuit Limit Switch Head |
Protection |
Standard type |
Protection Class |
IP67 |
Switch Type |
General built-in switch 1A1B contact type |
Actuator Type |
Seal, top roller, plunger |
Model No |
WLD28-LE-N |
Monotaro ID |
66528315 |
Mass (g) |
Approximately 255 (for type WLCA2-N) |
Rated Frequency (Hz) |
50/60 |
Terminal Screw |
4-M3.5 |
Energizing Current (A) |
10 |
Load Connection |
General load / micro load shared |
Import Country |
Direct Import from Japan |
Terminal Shape |
Screw tightening terminal (conduit size G1 / 2) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (No Icing) |
Contact Resistance (ohm) |
25 mΩ or less (initial value, built-in switch only) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Remark |
Confirm Delivery Date Each Time |
