| Type | Set type (4-circuit double-cut type) |
| Country of Origin | JAPAN |
| Shape | General-purpose vertical type |
| Type of Product | Compact Heavy Equipment Limit Switch |
Type |
Set type (4-circuit double-cut type) |
Country of Origin |
JAPAN |
Shape |
General-purpose vertical type |
Type of Product |
Compact Heavy Equipment Limit Switch |
Mechanical Durability |
Over 30 million times (4-circuit double break rotating lever type), *Retaining type is excluded. |
Shock Resistance |
1000m/s² Or More |
Allowable Operating Speed |
1 mm to 2 M/S (D4A-3101N, Rotating Lever Type) |
Protection Class |
(Compliant) IP67, NEMA standards 1, 2, 3, 4, 4X, 5, 6P, 12, 13 |
Model No |
D4A-2514N |
Monotaro ID |
46532342 |
Withstand Voltage |
(between terminals of the same polarity), AC 1000 V 50/60 Hz 1min, (Between live metal parts and earth), AC 2200 V 50/60 Hz 1min, (Between each terminal and non-current-carrying metal parts), AC 2200 V 50/60 Hz 1 min |
Contact Configuration |
2A2B |
Mass (g) |
Approx. 290 (D4A-3101N rotating lever type) |
Rated Frequency (Hz) |
50/60 |
Operation Indicator Lamp |
None |
Operation Type |
Snap action |
Head Shape |
Flexible rod type, plastic rod type |
Temperature Rise |
50deg or less |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-20 to 100 |
Contact Resistance (ohm) |
25 mΩ or less (initial value) |
Insulation Resistance (MOhm) |
Between terminals of the same polarity, between live metal parts and earth, between each terminal and non-live metal parts, 100 or more (DC500V megger) |
Remark |
Confirm Delivery Date Each Time |
