Ships within 25 days
Mass (g)
Cable Length (m)
Model No
View
View
View
View
| Type | Compact Limit Switch |
| Country of Origin | JAPAN |
| Shape | General-Purpose Vertical Type |
| Type of Product | Limit Switch |
Type |
Compact Limit Switch |
Country of Origin |
JAPAN |
Shape |
General-Purpose Vertical Type |
Type of Product |
Limit Switch |
Insulation Resistance |
100 mΩ Or more (With DC 500 V Mega) |
Protection Class |
IP67 |
Actuator Type |
Pin Plunger Type |
Model No |
D4C-1301 |
Monotaro ID |
39038054 |
Withstand Voltage |
Between Terminals Of The Same Polarity: AC 1000 (50/60 Hz), Between Live Metal Parts And Earth: AC 1500 (50/60 Hz)/Uimp 2.5 Kv (En60947-5-1), Between Each Terminal And Non-Live Metal Parts: AC 1500 (50/60 Hz)/Uimp 2.5Kv (En60947-5-1) |
Contact Configuration |
1c |
Mass (g) |
Approx. 540 (With D4C-1202 / Vctf5M) |
Rated Frequency (Hz) |
50/60 |
Cable Length (m) |
5 (VCTF Oil-Resistant Cord) |
Rated Insulation Voltage (V) |
(Ui)300(EN60947-5-1) |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
