| Type | Environmentally resistant type (standard type) |
| Country of Origin | JAPAN |
| Type of Product | General Limit Switch |
| Mechanical Durability | 15 million times or more |
Type |
Environmentally resistant type (standard type) |
Country of Origin |
JAPAN |
Type of Product |
General Limit Switch |
Mechanical Durability |
15 million times or more |
Allowable Operating Speed |
1 mm to 1m / s (for type WLCA2-N) |
Protection Class |
IP67 |
Electrical Durability |
750,000 times or more (250VAC, 3A, with resistive load) |
Actuator Type |
Side roller plunger |
Model No |
WLSD2-RP139-N10M |
Monotaro ID |
66530774 |
Mass (g) |
Approx. 250 (for WLCL-TH-N) |
Rated Frequency (Hz) |
50/60 |
Cable Length (m) |
10 |
Import Country |
Direct Import from Japan |
Terminal Shape |
Cable direct type |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (No Icing) |
Contact Resistance (ohm) |
25 mΩ or less (initial value, built-in switch only) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Specifications |
●Lever tightening specifications: Standard (hexagon socket head bolt) |
Remark |
Confirm Delivery Date Each Time |
