| Type | Environmental resistance type |
| Country of Origin | Japan |
| Type of Product | 2-Circuit Limit Switch |
| Mechanical Durability | 10 Million Times Or More |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Environmental resistance type |
Country of Origin |
Japan |
Type of Product |
2-Circuit Limit Switch |
Mechanical Durability |
10 Million Times Or More |
Allowable Operating Speed |
1 mm to 1 m/s (for WLCA2) |
Protection Class |
IP67 |
Actuator Type |
Variable roller lever type (overtravel type, general type, 80°) |
Model No |
WLH12-P1 |
Monotaro ID |
63703518 |
Mass (g) |
Approx. 275 (for WLCA2) |
Rated Frequency (Hz) |
50/60 |
Electrical ratings |
General load type |
Rated Insulation Voltage (V) |
250(EN60947-5-1) |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (No Icing) |
Contact Resistance (ohm) |
25 mΩ or Less (initial value, built-in switch only) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Specifications |
● Lever tightening specifications: Standard lever ● Leverless switch type: WLRH2 |
