| Country of Origin | Japan |
| Type of Product | 2-Circuit Limit Switch |
| Mechanical Durability | 15 million times or more |
| Allowable Operating Speed | 1 mm to 1 m / s (for WLCA2) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Country of Origin |
Japan |
Type of Product |
2-Circuit Limit Switch |
Mechanical Durability |
15 million times or more |
Allowable Operating Speed |
1 mm to 1 m / s (for WLCA2) |
Protection |
Standard type |
Protection Class |
IP67 |
Switch Type |
General built-in switch 1a1b contact type |
Electrical Durability |
750,000 times or more |
Actuator Type |
Roller lever type (high accuracy type) |
Ambient Humidity to Use |
35 to 95%RH |
Monotaro ID |
35459986 |
Electric Shock Protection Class |
ClassⅠ |
Rated Frequency (Hz) |
50/60 |
Electrical ratings |
Standard type |
Rated Insulation Voltage (V) |
(Ui)250(EN60947-5-1) |
Terminal Screw |
4-M4 |
Energizing Current (A) |
10 |
Operation Indicator Lamp |
Light emitting diode (LED) |
Hysteresis Distance |
Reference value: MD (maximum): 3 ° |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Vibration Resistance (Malfunction) |
10~55Hz double amplitude 1.5mm |
Operation Ambient Temperature (°C) |
-10-80 (no icing) |
Manufacturer Part Number |
WLGCA2-LDS |
Contact Resistance (ohm) |
25 or less (initial value) |
Insulation Resistance (MOhm) |
100 or more (with DC500V mega) |
