Ships within 25 days
View
View
View
View
| Type | Standard type (high sensitivity type/high accuracy type) |
| Country of Origin | Japan |
| Shape | General-purpose vertical type |
| Type of Product | 2-Circuit Limit Switch |
Type |
Standard type (high sensitivity type/high accuracy type) |
Country of Origin |
Japan |
Shape |
General-purpose vertical type |
Type of Product |
2-Circuit Limit Switch |
Protection |
Standard type |
Protection Class |
IP67 |
Switch Type |
General built-in switch 1a1b contact type |
Actuator Type |
Roller lever (R38mm) High sensitivity type |
Monotaro ID |
35459864 |
Mass (g) |
Approximately 270 (for type WLGCA2) |
Rated Frequency (Hz) |
50/60 |
Terminal Screw |
4-M3.5 |
Energizing Current (A) |
5 |
Load Connection |
General load / micro load shared |
Import Country |
Direct Import from Japan |
Terminal Shape |
Screw tightening terminal (conduit size G1 / 2) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (no icing) |
Manufacturer Part Number |
WLG2-LD |
Contact Resistance (ohm) |
25 or less (initial value, built-in switch only) |
Insulation Resistance (MOhm) |
100 or more (with DC500V mega) |
