| Type | Compact limit switch |
| Country of Origin | JAPAN |
| Shape | General-purpose vertical type |
| Type of Product | Compact Limit Switch |
Type |
Compact limit switch |
Country of Origin |
JAPAN |
Shape |
General-purpose vertical type |
Type of Product |
Compact Limit Switch |
Mechanical Durability |
10 Million Times Or More |
Allowable Operating Speed |
1 mm to 1 m/s |
Protection Class |
IP67 |
Electrical Durability |
1 million times or more (DC specification, switching current 0.1A) |
Actuator Type |
Roller lever type (high sensitivity type) |
Model No |
D4C-3024-M1J-0.3M |
Monotaro ID |
46521876 |
Withstand Voltage |
(between terminals of the same polarity), AC 1000 V 50/60 Hz 1min, (between live metal part and earth), AC 1500 V 50/60 Hz 1min/Uimp 2.5 kV(EN60947-5-1), (between each terminal and non-current-carrying metal parts), AC 1500 V 50/60 Hz 1min/Uimp 2.5kV(EN60947-5-1) |
Rated Sealed Thermal Current |
5A, 4A, 0.5A(En60947-5-1)(I The) |
Electric Shock Protection Class |
ClassⅢ |
Rated Frequency (Hz) |
50/60 |
Short Circuit Protection Device |
10A fuse gI or gG (IEC60269) |
Cable Length (m) |
0.3 |
Electrical ratings |
DC 30 V 1 Amp (with operation indicator) |
Inrush current (A) |
Normally closed circuit: Up to 20, Normally open circuit: Up to 10 |
Rated Insulation Voltage (V) |
(Ui)250(EN60947-5-1) |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to 70 (no icing) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
