| Type | Operation display type |
| Country of Origin | JAPAN |
| Shape | General-purpose vertical type |
| Type of Product | 2-Circuit Limit Switch |
Type |
Operation display type |
Country of Origin |
JAPAN |
Shape |
General-purpose vertical type |
Type of Product |
2-Circuit Limit Switch |
Protection Class |
IP67 |
Switch Type |
General built-in switch 1A1B contact type |
Actuator Type |
Plunger type (top ball / plunger type) |
Model No |
WLD3-LE |
Service Life |
General form |
Monotaro ID |
35460302 |
Withstand Voltage |
Between terminals of the same pole: AC 1000 V + 50 / 60 Hz + 1 min, between each terminal and ground: AC2200V + 50 / 60 Hz + 1 min / Uimp + 2.5kV, between each terminal and non-charged metal part: AC2200V + 50 / 60 Hz + 1 min / Uimp + 2.5kV |
Mass (g) |
Approx. 275 (for WLCA2) |
Rated Frequency (Hz) |
50/60 |
Rated Insulation Voltage (V) |
(Ui)250(EN60947-5-1) |
Terminal Screw |
4-M4 |
Energizing Current (A) |
10 |
Type of Sign |
Front mounting, rear mounting |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (No Icing) |
Contact Resistance (ohm) |
25 mΩ or Less (initial value, built-in switch only) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
