Ships within 19 days
Model No
No. of Pole
View
View
View
View
| Type of Product | D-Sub Connector Socket |
| Model No | XM3F-2520-112 |
| Total Insertion Force | Number of poles x 3.33N or less |
| Rated Voltage (V) | AC300 |
Type of Product |
D-Sub Connector Socket |
Model No |
XM3F-2520-112 |
Total Insertion Force |
Number of poles x 3.33N or less |
Rated Voltage (V) |
AC300 |
Monotaro ID |
46590451 |
Rated Current (A) |
3 |
No. of Pole |
25 |
Housing Material |
Glass-filled PBT resin (UL94V-0) / Black |
Contact Material |
(Contact area) Phosphor bronze/nickel base, gold plating (0.4 μm) (Terminal area) Phosphor bronze/nickel base, tin plating (3 μm) |
Shape |
Socket |
Country of Origin |
China |
Operating Temperature Range |
-55 to +105 ℃ (no freezing at low temperatures) |
Import Country |
Direct Import from Japan |
Terminal Shape |
Dip L-Shaped Terminal (With Ferrite Core) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Dimension A (Φmm) |
52.9 |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
15 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Dimension B (Φmm) |
47.04 |
Dimension C |
33.12 mm |
Dimension d |
1.38 mm |
Dimension F (Φmm) |
2.76 |
Dimension E (Φmm) |
30.36 mm |
Specifications |
Fixing / lock pin with grounding bracket |
Dimension H (Φmm) |
38.38 |
Dimension G |
41.04 mm |
