Ships within 19 days
Model No
No. of Pole
View
View
View
View
| Type of Product | D-Sub Connector Socket |
| Model No | XM3F-3720 |
| Rated Voltage (V) | AC300 |
| Monotaro ID | 39105245 |
Type of Product |
D-Sub Connector Socket |
Model No |
XM3F-3720 |
Rated Voltage (V) |
AC300 |
Monotaro ID |
39105245 |
Rated Current (A) |
3 |
No. of Pole |
37 |
Housing Material |
Glass-filled PBT resin (UL94V-0) / Black |
Contact Material |
(Contact area) Phosphor bronze/nickel base, gold plating (0.4 μm) (Terminal area) Phosphor bronze/nickel base, tin plating (3 μm) |
Shape |
Socket |
Country of Origin |
China |
Operating Temperature Range |
-55 to +105 ℃ (no freezing at low temperatures) |
Import Country |
Direct Import from Japan |
Terminal Shape |
Dip L-Shaped Terminal (With Ferrite Core) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Dimension A (Φmm) |
69.2 |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
15 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Dimension B (Φmm) |
63.5 |
Dimension C |
49.68 mm |
Dimension d |
1.38 mm |
Dimension F (Φmm) |
2.76 |
Dimension E (Φmm) |
46.92 mm |
Specifications |
Without fixture or grounding bracket |
Dimension H (Φmm) |
54.84 |
Dimension G |
57.6 mm |
