| Type of Product | Duct CO₂ Transmitter Ace |
| Accuracy | ±40 ppm ±2% of reading (5000–20,000 ppm), ±40 ppm ±3% of reading (up to 5000 ppm) |
| Model No | AI-CO2-D |
| Output | Field selectable 4–20 mA or 0–10 VDC |
Type of Product |
Duct CO₂ Transmitter Ace |
Accuracy |
±40 ppm ±2% of reading (5000–20,000 ppm), ±40 ppm ±3% of reading (up to 5000 ppm) |
Model No |
AI-CO2-D |
Output |
Field selectable 4–20 mA or 0–10 VDC |
Display |
Optional LCD display |
Power Supply |
24 V DC, 250 mA |
Response Time |
1 minute for 80% output, 3 minutes for stable accuracy |
Dimension |
Duct Probe: 150 mm (L) × 20 mm (Dia), Enclosure: 80 (W) × 120 (H) × 60 (D) mm |
Enclosure |
Duct-mounted ABS plastic enclosure with mounting bracket |
Country of Origin |
India |
Display Type |
Select - with Display, without Display |
Name of Manufacturer/Packer/Importer |
INSTRUKART HOLDING |
Operating Conditions |
-10 to + 60 °C |
Measure Range |
0 to 10000 ( Optional ), 0 to 2000 PPM Standard, 0 to 20000 ( Optional ), 0 to 5000 ( Optional ) |
Modbus |
Communication Optional RS-485 Modbus communication |
Sensor Type |
Standard Photoacoustic Sensor (PAS) from Switzerland / Optional Dual Beam NDIR Sensor |
Calibration |
Factory calibrated with individual calibration certificate |
